PCB Assembly Turnkey and Consignment Services

Whether you have an existing supply of parts and just need to cross the finish line, or you need full-service component and assembly services, Imagineering is ready to help.

PCB assembly is our business. For 37 years, we’ve helped over 30,000 clients design and perfect PCBs for every imaginable application. From aerospace and medical devices to automotive and consumer electronics, we’ve done it all.

We use a combination of expertise and technology that enables us to meet any quality standard, work with any supply of parts, and help you get your next product to market faster than the competition.

Why Choose Imagineering to Assemble Your PCBs?

We understand that PCBs are as unique and varied as the electronics they power. Each PCB must be approached from the ground-up with a holistic process that guarantees three things:

1.
The PCB design is optimized for manufacturing and assembly.
2.
The materials and components will meet every applicable industry standard.
3.
The boards will get done on-time, without errors, so our customers can get their products to market ahead of their competitors.

Here’s how we meet these goals

Rapid Prototyping

With turnaround times as short as 24 hours, we’ll rapidly build and test your PCB prototypes to ensure they’re ready for a full production run. This process eliminates the possibility of last-minute problems and helps optimize your final design.

DFM/DFA/CAM Support

These are computer-aided pre-production checks that ensure your designs are optimized for manufacturing and assembly. We use them to spot issues early and fix them before any work starts. This optimizes your boards while reducing costs and eliminating the chance of last-minute problems.

Production Runs of 1 to 100,000 Units

Our off-shore production facilities enable us to access economies of scale. Regardless of your needs, we can ramp up and adjust quickly, enabling larger and more complex production runs.

Cutting-Edge Technology

It’s one thing to know what needs to be done. It’s another to have the tools to do it. Our experienced engineers have access to the latest hardware and software systems that enable them to produce a wide variety of PCBs using the latest techniques. That includes:

We guarantee the quality of your boards through an on-going QA process that includes:

Automated optical inspection (AOI)

BGA X-Ray inspection

Full functionality testing

Full Certification

Part of our dedication to quality is staying on top of all relevant industry standards.
We are:

LET US ASSEMBLE YOUR NEXT PCB.

PCB Turnkey vs. Consignment Assembly Services

Imagineering is happy to offer both consignment and full turnkey PCB assembly services to our customers. Depending on your needs, one may be better than the other. Unsure what each one means?

Here’s a quick primer.

What is Turnkey PCB Assembly?

The key to modern PCB production is technology. Thanks to our constant investment in the latest hardware and software systems, we’re capable of producing the PCBs to meet any standard.

Our assembly capabilities include:

Ensuring your design is optimized for manufacturing.

Ordering parts and components.

Full PCB fabrication and assembly.

State-of-the-art quality control.

Packaging and shipping.

Turnkey PCB assembly is an ideal choice for those who need a fast, reliable PCB production run but don’t have the parts or facilities needed to do it alone. It has the added benefit of eliminating the need for multiple vendors or assembly facilities, which not only controls costs but reduces the risk of major errors that delay getting your product to market.

What is Consignment PCB Assembly?

Consignment PCB assembly allows you to send us your own supply of parts and components and have us assemble them to your specifications.

With our consignment services, you’ll get:

Access to a full inventory service that includes verification of your kits, climate-controlled parts storage, and warehousing of your parts for your next project.

DFM/DFA/CAM Checks.

Full PCB Assembly.

Our state-of-the-art quality assurance.

Packaging and on-time shipping guaranteed.

For those manufacturers who may have an existing supply chain or stock of parts, and who just require an assembler to put everything together, consignment PCB assembly services are ideal. They allow you full control over the supply (and therefore the quality) of the materials used in your PCBs while still having access to the equipment and expertise Imagineering can offer.
