Fabrication Capabilities

Choose the experts for bare board fabrication and circuit board manufacturing. Imagineering offers quick turnarounds, same-day prototypes and production in 5-7 days for multi-layer rigid and flex PCB fabrication. With our domestic and offshore manufacturing facilities, you’ll receive aerospace quality at standard prices.

Our fabrication capabilities include up to 50 layers, hole sizes down to 8 mil. plated and 5 mil. laser drilled, 2/1.5 mil. line width and spacing, 16 oz. copper and a maximum PCB thickness up to .300″.

Imagineering offers small volume production in 5-6 days and medium-to-large volume production in 2-3 weeks.

Imagineering technology roadmap

Technology Roadmap

See our technology roadmap for the specifications you need to know for fabrication.

Learn More
materials for circuit board projects

Materials Available

Choose from a wide range of materials for next circuit board projects.

Learn More
HDI PCB

HDI

Utilize smaller components and enable higher wiring density per unit area with HDIs.

Learn More
PCB tolerance guidelines

Tolerances

Use our tolerance guidelines to ensure the best results for your printed circuit boards.

Learn More
Imagineering’s industry leading certifications

Certifications

Stay assured of quality with Imagineering’s industry-leading certifications.

Learn More
